Product Description
Software function for Linux IPTV Box:
More DVB IPTV Box model please click:https://www.eri-tech.com/product-category/set-top-box/iptv-box/
High performance 32-bit CK610M CPU integrates 16Kbytes instruction cache and 16Kbytes data cache. Provides up to 1500 DMIPS. JTAG debug supported n
SPI NOR or SPI NAND flash n
Built-in 128MB DDR3 SDRAM
The multi-standard video decoder supports JPEG/MJPEG, MPEG2, AVS, AVS plus, MPEG4, H.264, H.265 10bit/60fps HD or SD advanced video decoding. Error protection and concealment supported
The audio decoder supports MPEGI/II, MP3, Dolby Digital optional, Dolby Digital Plus optional, MPEG4 AAC, HE-AAC and DRA decoding. The output supports L/R and S/PDIF.
All of the PAL and NTSC analog TV standards supported.
4 channel video DAC integrated, and the following output modes are supported: 2CVBS/S-Video, CVBS/YCbCr, CVBS/RGB, YPbPr and RGB(progressive).
HDMI , HDCP and DVI compliant transmitter embedded.
2 channel audio DACs integrated, S/N is more than 90 dB.
2 USB2.0 Host integrated, High-speed and Full-speed devices supported.
A 10M/100M Ethernet MAC integrated.
Support standby mode.
